Specifications

PRICING

Price	Standard
Price - Warranty (Months)	12

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	4-Stroke
Engine - Cooling	Liquid
Engine - Valves	4
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	DOHC
Engine - Bore (mm)	74
Engine - Bore (in)	2.92
Engine - Stroke (mm)	58
Engine - Stroke (in)	2.46
Engine - Displacement (cc)	249
Engine - Displacement (ci)	15.2
Engine - Compression Ratio	11:1
Engine - Starter	Electric / Kick
Carburetion	Standard
Carburetion - Carburetion Brand	Keihin
Carburetion - Fuel Injector	No
Carburetion - Carburetor	Yes
Carburetion - Number Of Carburetors	1
Carburetion - Carburetor Size (mm)	34
Carburetion - Carburetion Type	Carburetor

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	6
Transmission - Overdrive	Yes
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Gear Ratio (1)	3
Transmission - Gear Ratio (2)	2
Transmission - Gear Ratio (3)	1.5
Transmission - Gear Ratio (4)	1.25
Transmission - Gear Ratio (5)	1.05
Transmission - Gear Ratio (6)	0.9
Transmission - Final Drive Ratio	2.93

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	84.3
Dimensions - Length (mm)	2141.2
Dimensions - Width (in)	33.7
Dimensions - Width (mm)	856
Dimensions - Height (in)	47.6
Dimensions - Height (mm)	1209
Dimensions - Wheelbase (in)	55.7
Dimensions - Wheelbase (mm)	1414.8
Dimensions - Ground Clearance (in)	10.6
Dimensions - Ground Clearance (mm)	269.2
Dimensions - Length (ft)	7.02
Dimensions - Length (ft/ft)	7
Dimensions - Length (ft/in)	0.3
Weight	Standard
Weight - Dry Weight (lbs)	258
Weight - Dry Weight (kg)	117
Weight - Wet Weight (lbs)	293.2
Weight - Wet Weight (kg)	133
Capacities	Standard
Capacities - Fuel Capacity (gal)	2.9
Capacities - Fuel Capacity (l)	11
Performance	Standard
Performance - Engine Displacement to Weight (cc)	0.97

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver and Passenger
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Kick
Handlebars	Standard
Skid Plate	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Telescopic Fork
Front Suspension - Front Suspension Size (in)	1.4
Front Suspension - Front Suspension Size (mm)	36
Front Suspension - Front Travel (in)	9.1
Front Suspension - Front Travel (mm)	231.1
Front Suspension - Front Adjustable Fork Pre-Load	No
Front Suspension - Front Adjustable Rebound Damping	No
Front Suspension - Front Central Suspension Strut	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	9.1
Rear Suspension - Rear Travel (mm)	231.1
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	Yes
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Brand Name	UNI-TRAK®

WHEELS & TIRES

Wheels	Standard
Wheels - Tube / Tubeless	Tubed
Wheels - Front Wheel Width (in)	3
Wheels - Rear Wheel Width (in)	4.6
Tires	Standard
Tires - Front Wheel Diameter	21
Tires - Rear Wheel Diameter	17
Tires - Front Tire (Full Spec)	3 X 21
Tires - Rear Tire (Full Spec)	4.6 X 17

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Rear Brake Type	Drum

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver and Passenger
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	33.7
Seat Specifications - Seat Height (mm)	856
Seat Specifications - Number Of Seats	2
Seat Backrest - Backrest Logo Plate	No

INSTRUMENTATION

Tachometer	Standard
Trip Odometer	Standard
Speedometer	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Gauge
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Gauge

STORAGE

Tail Bag	Standard
Tail Bag - Tail Bag Material	Vinyl

LIGHTS

Halogen Headlight(s)	Standard
Headlight(s)	Standard
Headlight(s) - Type	Halogen

GLASS

Rearview Mirrors

Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	No

AUDIO & COMMUNICATION

Radio - Satellite

No

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
