All Hail the King

Boasting GYTR performance parts, unique color and graphics, and unmatched performance, this machine is Sport ATV royalty.

Key Features

Top Features

Aggressive SE Style

Aggressive styling lends the Raptor 700R SE the menacing looks to match its impressive performance. With added features like a dealer-installed GYTR® front grab bar and heel guards to match its unique graphics package, the mighty Raptor 700R SE is ready to go whether the destination is the dunes, the trails or the track.

Big-Bore Power

Powered by our most potent 686cc, liquid-cooled, fuel-injected Raptor engine ever, this big-bore Sport ATV produces big torque right off idle, transitioning into a fat mid-range, and monstrous top-end.

Advanced Chassis

Big power and lightweight, a combination that makes any ATV rider take notice, come standard on the Raptor 700R SE. With a hybrid steel aluminum frame, Controlled-Fill aluminum sub-frame and cast aluminum swingarm, this combination produces a super-strong structure and the lightest ATV in its class.

Rider-Friendly Features

A thick comfortable seat provides excellent comfort while the dual counterbalancers, electric starter and reverse gear keep things nice and civilized when needed. But when it comes time to pull the trigger, the big-bore Raptor 700R SE stands tall.

Advanced Suspension

The YFZ-inspired handling of the Raptor 700R SE is incredible to experience while blasting through the woods. Thanks to the 9.1 inches of front travel and 10.1 inches out back, the trail bumps smooth out while the rider keeps things under control. With the combination of power, solid handling and a great suspension, this machine has to be experienced to be fully appreciated.

Engine

Smooth, Powerful Engine

The forged lightweight piston, connecting rod and crankshaft in the 686cc engine are light and strong for a hard-hitting, quick-revving powerplant that revs all the way to 9,000 rpm while the dual counterbalancers keep it smooth.

Advanced Fuel Injection

The Yamaha Fuel Injection (YFI) offers consistent and excellent engine performance in a wide range of conditions, elevations and temperatures.

Digital Ignition

The digital TCI with 32-bit electronic control unit controls fuel injection and ignition systems for consistent performance and fantastic throttle response.

Electric Starter

Reliable push-button electric start in any gear adds extra convenience.

Robust Transmission

Race-bred five-speed transmission with reverse, along with Raptor the 700R SE's monstrous powerband, means there's a choice of gears in just about all situations. YZ-spec ratchet shifter ensures smooth, resistance-free shifting under power while the heavy-duty clutch features a sturdy basket and plates designed to harness the power.

Excellent Serviceability

Easy-to-reach oil filter and tool-free air filter provide added convenience.

Chassis/Suspension

High-Tech Chassis

The state-of-the-art chassis combines a steel front section with a YZ-style piggyback rear shock that gives 10.1-inch wheel travel along with preload adjustment.

Advanced Suspension

YZ-style piggyback shocks are fully adjustable with high- and low-speed compression adjustability for maximum sport versatility along with preload and rebound adjustment. Front wheel travel is a plush 9.1 inches while the rear shock provides 10.1 inches of wheel travel.

Powerful Brakes

Twin aluminum-piston front disc brakes deliver tremendous stopping power. Discs are drilled, which helps reduce unsprung weight for excellent suspension compliance with an additional twin-piston rear brake for maximum stopping power.

Aggressive Maxxis® Tires

High-performance 22x7-10 front and 20x10-9 rear Maxxis® tires with a specially designed tread pattern deliver superb, class-leading traction for razor-sharp handling in a variety of terrain and conditions.

Lightweight Wheels

Lightweight aluminum wheels help enhance suspension performance by reducing unsprung weight.

Wide Foot Pegs

Race-inspired 45mm serrated foot pegs provide excellent boot traction.

Strong Frame

The Controlled-Fill aluminum subframe and composite front grab bar are both light yet strong.

Additional Features

Sporty Ergonomics

The long, YZ-style seat allows maximum rider comfort and movement with superb sport-riding ergonomics.

High Visibility Lighting

Multi-reflector 30-watt Krypton headlights that are set back in the front cowl add the perfect, no-compromises sporting accent, and an LED taillight provides great visibility.

Large Fuel Tank

Large-capacity, 2.9-gallon fuel tank and Yamaha Fuel Injection (YFI) mean more time on the trail between fill-ups.

Ergonomic Controls

Thumb throttle lever has a smooth shape for a feel riders will appreciate creating less fatigue at the end of the day while the handlebar-mounted flip-type parking brake lever is simple to use.

Yamaha Diagnostic Tool

For improved serviceability, the Raptor 700R SE is Yamaha Diagnostic Tool-ready.

Assembled in the USA

The Raptor 700R SE is proudly assembled in the USA.

Specifications

Engine

Engine Type - 686cc liquid-cooled SOHC 4-stroke; 4 valves

Bore x Stroke - 102.0mm x 84.0mm

Compression Ratio - 10.0:1

Fuel Delivery - Yamaha Fuel Injection (YFI), 44mm

Ignition TCI: Transistor Controlled Ignition

Transmission - 5-speed w/reverse; wet multiplate clutch

Final Drive - X-ring chain; 2WD

Fuel Capacity - 2.9 gal

Chassis

Suspension/Front - Independent double wishbone w/piggyback high/low-speed compression, rebound and threaded preload adjustment, 9.1-in travel

Suspension/Rear - Cast aluminum swingarm w/piggyback high/low-speed compression, rebound and threaded preload adjustment, 10.1-in travel

Brakes/Front - Dual hydraulic disc

Brakes/Rear - Hydraulic disc

Tires/Front - AT22 x 7-10 Maxxis®

Tires/Rear - AT20 x 10-9 Maxxis®

Dimensions

LxWxH - 72.6 in x 45.5 in x 43.9 in

Seat Height - 32.7 in

Wheelbase - 50.4 in

Max. Ground Clearance - 9.5 in

Fuel Capacity - 2.9 gal

Wet Weight*** - 422 lb

Other

Warranty - 6 Month (Limited Factory Warranty)
