Specifications

PRICING

Price	Standard
Price - Warranty (Months)	6
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	4-Stroke
Engine - Cooling	Liquid / Oil
Engine - Valves	4
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	SOHC
Engine - Bore (mm)	102
Engine - Bore (in)	4.02
Engine - Stroke (mm)	84
Engine - Stroke (in)	3.31
Engine - Displacement (cc)	686
Engine - Displacement (ci)	41.9
Engine - Compression Ratio	9.2:1
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Carburetion	Standard
Carburetion - Fuel Injector	Yes
Carburetion - Fuel Injector Size (mm)	41
Carburetion - Carburetor	No
Carburetion - Carburetion Type	Fuel Injected

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Continuously Variable (CVT)
Transmission - Overdrive	No
Transmission - Primary Drive (Rear Wheel)	Shaft
Transmission - Primary Drive (Engine / Transmission)	Belt
Transmission - Reverse	Yes
Transmission - Transmission Brand	UltraMatic™
Transmission - Hi / Low Range	Yes
Transmission - Primary Drive (Front Wheel)	Shaft

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	113.6
Dimensions - Length (mm)	2885.4
Dimensions - Width (in)	56.6
Dimensions - Width (mm)	1437.6
Dimensions - Height (in)	73
Dimensions - Height (mm)	1854.2
Dimensions - Wheelbase (in)	75.2
Dimensions - Wheelbase (mm)	1910.1
Dimensions - Turning Radius (ft)	12.8
Dimensions - Ground Clearance (in)	12.1
Dimensions - Ground Clearance (mm)	307.3
Dimensions - Length (ft)	9.47
Dimensions - Length (ft/ft)	9
Dimensions - Length (ft/in)	5.6
Weight	Standard
Weight - Towing Capacity (lbs)	1212
Weight - Towing Capacity (kgs)	549.8
Capacities	Standard
Capacities - Fuel Capacity (gal)	7.9
Capacities - Fuel Capacity (l)	29.9
Performance	Standard
Performance - Engine Displacement to Weight (cc)	0.57

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Exterior Guards	Standard
Exterior Guards - Chain Guard	No
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Engine Case Guard	No
Exterior Guards - Brush Guard	Yes
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Radiator Guard	Yes
Exterior Guards - Front Mud Guards	Yes
Exterior Guards - Rear Mud Guards	No
Exterior Covers	Standard
Exterior Covers - CV Boot Cover	Yes
Front Bumper	Standard
Skid Plate	Standard
Skid Plate - Bash Plate (Front)	Yes
Skid Plate - Swing Arm Skid Plate	No
Skid Plate - Full Length Skid Plate	No
Skid Plate - Drive Shaft Skid Plate	No
Cab Cage	Standard
Cab Rollbar	Standard
Cab Doors	Standard
Cab Doors - Cab Door Material	Hard
Cab Doors - Camouflage	No
Cab / Bed Divider	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Independent Double Wishbone
Front Suspension - Front Travel (in)	7.3
Front Suspension - Front Travel (mm)	185.4
Front Suspension - Front Adjustable Fork Pre-Load	Yes
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Independent Double Wishbone
Rear Suspension - Rear Travel (in)	7.3
Rear Suspension - Rear Travel (mm)	185.4
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Number Rear Shock Absorbers	2
Rear Suspension - Adjustment Type	Spring Mounted Adjustment
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubeless
Wheels - Front Tire Diameter (in)	25
Wheels - Rear Tire Diameter (in)	25
Tires	Standard
Tires - Tire Brand	Maxxis®
Tires - Front Tire Width	8
Tires - Front Wheel Diameter	12
Tires - Rear Tire Width	10
Tires - Rear Wheel Diameter	12
Tires - Front Tire (Full Spec)	Maxxis® 25 X 8-12 NHS
Tires - Rear Tire (Full Spec)	Maxxis® 25 X 10-12 NHS
Tires - Tread Type	All Terrain

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Dual Hydraulic Disc
Brakes - Rear Brake Type	Dual Hydraulic Disc
Engine Braking	Standard

SEATS

Seat	Standard
Seat - Seat Type	Bucket
Seat - Seat Material	Vinyl
Seat - Folding	No
Seat - Headrest	Yes
Seat Specifications	Standard
Seat Specifications - Number Of Seats	2
Seat Specifications - Number Of Rows	1
Grab Rail or Strap	Standard

INSTRUMENTATION

Digital Instrumentation	Standard
Clock	Standard
Trip Odometer	Standard
Speedometer	Standard
Hour Meter	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Light
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Gauge

STORAGE

Cupholder	Standard
Cupholder - Number Of Cupholders	2
Cargo Bed	Standard
Cargo Bed - Bed Capacity (lbs.)	400
Cargo Bed - Bed Capacity (kgs.)	181.4
Cargo Bed - Cargo Bed Tilt	Yes
Cargo Bed - Cargo Bed Material	Steel
Cargo Bed - Integral Tie-Down Hooks	Yes
Glove Box / Dash Storage	Standard

LIGHTS

Halogen Headlight(s)	Standard
Headlight(s)	Standard
Headlight(s) - Type	Halogen

CONVENIENCE

Power Outlet	Standard
Seat Belts	Standard

PAINT & FINISH

Paint	Standard
Paint - Metallic	No

DRIVE LINE

Driveline	Standard
Driveline - Driveline Brand	On-Command™
Driveline - Driveline Type	Selectable 4X2 / 4X4
Driveline - Number Of Driveline Modes	2
Driveline - Rear Unlocking Differential	No
Driveline - Rear Solid Axle	No
Limited Slip Differential	Standard
Limited Slip Differential - Limited Slip Differential Location	Front
Differential Lock	Standard
Differential Lock - Differential Lock Location	Front

STEERING

Steering	Standard
Steering - Steering Type	Rack & Pinion
Steering - Steering Control	Steering Wheel

TOWING & HAULING

Rear Hitch	Standard
Rear Hitch - Size (in)	2
Rear Hitch - Size (cm)	5.1
Rear Hitch - Rear Hitch Type	Receiver

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
