The Fun Starts Here

The push button electric start, three speed automatic transmission and adjustable speed restrictor make this the ideal bike to teach the thrill of riding.

Key Features

Top Features

Accessible Performance

Great for learning and playing, the TT-R50E features a fun, 49cc four-stroke engine feeding power through a three-speed automatic-clutch transmission.

Ultra-Low Seat Height

With a seat that's only 21.9 inches from the dirt, this bike brings big YZ styling to those with smaller statures.

Advanced Suspension

Conventional fork and Monocross® rear end provide great handling.

Convenient Electric Start

Convenient push-button electric start feature for effortless engine startup.

Robust Final Drive

Large chain cover for maximum protection and minimal maintenance.

Engine

Useable, Entry-Level Engine

The 49cc air-cooled SOHC powerplant puts out smooth, reliable four-stroke power that is perfect for kids and smaller beginners.

Automatic Clutch

Three-speed gearbox with automatic centrifugal clutch makes learning to shift gears a breeze.

Convenient Electric Start

Convenient push-button electric start feature for effortless engine startup.

Compact Engine

Compact design keeps overall engine width down for a narrow feel and great handling.

Responsive Power

Crisp, dependable throttle response from the 11mm Mikuni® VM-type carburetor with automatic on/off electric heater.

Low Maintenance Engine

Automatic cam chain tensioner reduces maintenance.

Digital Ignition

CDI ignition system delivers hot, reliable spark and requires minimal maintenance.

Forest-Friendly Exhaust

Lightweight, upswept exhaust system is quiet and contains a USFS-approved spark arrestor.

Chassis/Suspension

Simple and Strong Frame

The curved steel backbone frame keeps the TT-R50E narrow and has three engine-mounting points for excellent rigidity and handling.

Compact Conventional Fork

Conventional fork with 22mm sliders provides 3.8 inches of front wheel travel for great handling and a smooth ride.

Lightweight Single Shock

Monocross® rear suspension is controlled by a single coil-over shock and provides 2.8 inches of bump-smothering rear wheel travel.

Enclosed Drum Brakes

Front and rear 80mm drum brakes deliver strong, dependable stopping power, and the rear is activated by a right foot pedal just like the big YZs.

Durable Knobby Tires

Durable knobby tires mounted on 10-inch front and rear wheels offer great grip and exceptional wear.

Ultra-Low Seat Height

Low 21.9-inch seat height allows easy feet-down control for enhanced confidence.

Additional Features

Standard Security

Key-type ignition switch deters unauthorized riding.

Adjustable Restrictor

Throttle stop screw lets the adult supervisor restrict speed while beginners are learning.

Racing Style

Cool looking competition-style YZ bodywork includes an integrated front fender and number plate.

Folding Side Stand

Standard side stand tucks up out of the way when not in use.

Grippy Foot Pegs

Large folding, cleated foot pegs provide excellent footing

Specifications

Engine

Engine Type - 49cc air-cooled SOHC 4-stroke; 2 valves

Bore x Stroke - 36.0mm x 48.6mm

Compression Ratio - 9.5:1

Fuel Delivery - Mikuni® VM11 carburetor

Ignition - CDI

Transmission - Constant-mesh 3-speed; automatic clutch

Final Drive - Chain

Fuel Capacity - 0.8 gal

Chassis

Suspension/Front - Telescopic fork; 3.8-in travel

Suspension/Rear - Single shock; 2.8-in travel

Brakes/Front - Drum, 80mm

Brakes/Rear - Drum, 80mm

Tires/Front - 2.50-10-4PR

Tires/Rear - 2.50-10-4PR

Dimensions

LxWxH - 51.4 in x 23.4 in x 31.3 in

Seat Height - 21.9 in

Wheelbase - 36.4 in

Rake (Caster Angle) - 25.5°

Trail - 1.3 in

Max. Ground Clearance - 5.3 in

Fuel Capacity - 0.8 gal

Wet Weight*** - 128 lb

Other

Warranty - 90 Day (Limited Factory Warranty)
