2021 Yamaha Kodiak 700

MSRP:   $7299

* Plus Applicable Charges

Highlights


Pine Grove, PA
New
2021
Yamaha
Kodiak 700
GRN
ATV
Utility
Single-Cylinder
Continuously Variable (CVT)
04039

RECENTLY VIEWED

info specifications
2021 Yamaha Kodiak 700

The Yamaha Kodiak 700 is a utility style ATV with an MSRP of $7,299 and is carryover for 2021. Power is provided by a 4-Stroke, 686cc, Liquid cooled, SOHC, Single-Cylinder engine with Electric starter. The engine is paired with The Kodiak 700 rides on Steel wheels with Maxxis AT25 x 8 - 12 MU19 front tires and a Maxxis AT25 x 10 - 12 MU20 rear tires. The front suspension is an Independent Double Wishbone while the rear suspension is an Independent Double Wishbone. Front Dual Hydraulic Disc brakes and rear Sealed Oil Bath Multi-Disc brakes provide stopping power. The Kodiak 700 comes standard with an One-Piece, 1-passenger seat.

Specifications

PRICING

Price Standard
Price - MSRP 7299
Price - Currency US Dollars
Price - Warranty (Months) 6
Price - Destination Charge 425
Price - MSRP + Destination 7724
Price - Warranty (Condition) Limited

ENGINE

Engine Standard
Engine - Engine Type Single-Cylinder
Engine - Cylinders 1
Engine - Engine Stroke 4-Stroke
Engine - Cooling Liquid
Engine - Valve Configuration SOHC
Engine - Bore (mm) 102
Engine - Bore (in) 4.02
Engine - Stroke (mm) 84
Engine - Stroke (in) 3.31
Engine - Displacement (cc) 686
Engine - Displacement (ci) 41.8
Engine - Compression Ratio 10.0:1
Engine - Starter Electric
Engine - Fuel Requirements Regular
Engine - Fuel Type Gas
Carburetion Standard
Carburetion - Fuel Injector Yes
Carburetion - Fuel Injector Size (mm) 44
Carburetion - Carburetor No
Carburetion - Number Of Carburetors 0
Carburetion - Carburetion Type Fuel Injected
Parental Controls - Speed Governor No
Kill Switch / Tether Cord Standard

TRANSMISSION

Transmission Standard
Transmission - Transmission Type Continuously Variable (CVT)
Transmission - Primary Drive (Rear Wheel) Shaft
Transmission - Primary Drive (Engine / Transmission) Belt
Transmission - Reverse Yes
Transmission - Transmission Brand UltraMatic™
Transmission - Hi / Low Range Yes
Transmission - Primary Drive (Front Wheel) Shaft

TECHNICAL SPECIFICATIONS

Dimensions Standard
Dimensions - Length (in) 81.5
Dimensions - Length (mm) 2070.1
Dimensions - Width (in) 46.5
Dimensions - Width (mm) 1181.1
Dimensions - Height (in) 48.8
Dimensions - Height (mm) 1239.5
Dimensions - Wheelbase (in) 49.2
Dimensions - Wheelbase (mm) 1249.7
Dimensions - Turning Radius (ft) 10.5
Dimensions - Ground Clearance (in) 10.8
Dimensions - Ground Clearance (mm) 274.3
Dimensions - Length (ft) 6.79
Dimensions - Length (ft/ft) 6
Dimensions - Length (ft/in) 9.5
Weight Standard
Weight - Wet Weight (lbs) 659
Weight - Wet Weight (kg) 298.9
Weight - Payload Capacity (lbs) 308
Weight - Payload Capacity (kgs) 139.7
Weight - Towing Capacity (lbs) 1322
Weight - Towing Capacity (kgs) 599.7
Capacities Standard
Capacities - Fuel Capacity (gal) 4.8
Capacities - Fuel Capacity (l) 18.2
Performance Standard
Performance - Engine Displacement to Weight (cc) 1.04

EXTERIOR

Construction Standard
Construction - Frame Steel
Construction - Body Material Plastic
Floor Boards Standard
Floor Boards - Floor Board Location Driver
Hand Grips Standard
Foot Pegs Standard
Foot Pegs - Foot Peg Location Driver
Foot Pegs - Adjustable No
Exterior Guards Standard
Exterior Guards - Brush Guard Yes
Exterior Guards - Light Guard No
Exterior Guards - Radiator Guard No
Exterior Covers Standard
Exterior Covers - CV Boot Cover Yes
Exterior Covers - Shock Cover No
Front Fender Standard
Rear Fender Standard
Handlebars Standard
Front Bumper Standard
Skid Plate Standard
Skid Plate - Bash Plate (Front) Yes
Skid Plate - Bash Plate (Rear) Yes
Skid Plate - Swing Arm Skid Plate No
Skid Plate - Full Length Skid Plate Yes

SUSPENSION

Front Suspension Standard
Front Suspension - Front Suspension Type Independent Double Wishbone
Front Suspension - Front Travel (in) 7.1
Front Suspension - Front Travel (mm) 180.3
Front Suspension - Front Adjustable Fork Pre-Load No
Front Suspension - Front Adjustable Rebound Damping No
Front Suspension - Front Central Suspension Strut No
Front Suspension - Steering Damper No
Front Suspension - Front Stabilizer Bar No
Rear Suspension Standard
Rear Suspension - Rear Suspension Type Independent Double Wishbone
Rear Suspension - Rear Travel (in) 9.1
Rear Suspension - Rear Travel (mm) 231.1
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load No
Rear Suspension - Rear Adjustable Rebound Damping No
Rear Suspension - Number Rear Shock Absorbers 2
Rear Suspension - Rear Suspension Material Steel
Rear Suspension - Rear Stabilizer Bar Yes
Rear Suspension - Air Adjustable No

WHEELS & TIRES

Wheels Standard
Wheels - Wheels Composition Steel
Wheels - Tube / Tubeless Tubeless
Wheels - Front Tire Diameter (in) 25
Wheels - Rear Tire Diameter (in) 25
Wheels - Chromed No
Tires Standard
Tires - Tire Brand Maxxis®
Tires - Front Tire Width 8
Tires - Front Wheel Diameter 12
Tires - Rear Tire Width 10
Tires - Rear Wheel Diameter 12
Tires - Front Tire (Full Spec) Maxxis® AT25 x 8 - 12 MU19
Tires - Rear Tire (Full Spec) Maxxis® AT25 x 10 - 12 MU20

BRAKES

Brakes Standard
Brakes - Front Brake Type Dual Hydraulic Disc
Brakes - Rear Brake Type Sealed Oil Bath Multi-Disc
Engine Braking Standard

SEATS

Seat Standard
Seat - Seat Type One-Piece
Seat - Adjustable No
Seat - Seat Material Vinyl
Seat - Seat Location Driver
Seat - Folding No
Seat Specifications Standard
Seat Specifications - Seat Height (in) 33.9
Seat Specifications - Seat Height (mm) 861.1
Seat Specifications - Number Of Seats 1

INSTRUMENTATION

Digital Instrumentation Standard
Temperature Warning Standard
Temperature Warning - Temperature Warning Type Light
Fuel Level Warning Standard
Fuel Level Warning - Fuel Level Warning Type Gauge

STORAGE

Rear Rack Standard
Rear Rack - Capacity (lbs) 198
Rear Rack - Capacity (kgs) 89.8
Front Rack Standard
Front Rack - Capacity (lbs) 110
Front Rack - Capacity (kgs) 49.9
Glove Box / Dash Storage Standard

LIGHTS

Halogen Headlight(s) Standard
Headlight(s) Standard
Headlight(s) - Type Halogen

CONVENIENCE

Power Outlet Standard

PAINT & FINISH

Paint Standard

DRIVE LINE

Driveline Standard
Driveline - Driveline Type Selectable 4X2 / 4X4
Driveline - Number Of Driveline Modes 2
Driveline - Rear Unlocking Differential No
Driveline - Rear Solid Axle No
Limited Slip Differential Standard
Limited Slip Differential - Limited Slip Differential Location Front

STEERING

Steering Standard
Steering - Steering Type Manual
Steering - Steering Control Handlebar

TOWING & HAULING

Tow Hook Standard

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
